AIT- L3 Rainfall Sensor Rain Guage | |
 | |
Technical Parameters | |
Water Inlet Diameter | Φ 200+0.6mm |
Measuring Rainfall Intensity | ≤4mm/min(Operable at 8mm/min) |
Resolution | 0.2mm（Customizable based on user requirements） |
Error | ±3％（Indoor static test, when rain intensity is 2mm/min） |
Sensitivity | ≤0.02mm |
Output Signal | Single dry-reed switch on/off |
Working Temperature | -25～50℃ |
Operating Temperature in High-Altitude/Frigid Regions | -40～40℃ |
Storage Temperature | -10℃~50℃ |
Switching Capacity | DC,V≤12V ，I≤500mA |
Contact Switching Cycles | 1×10 Times |
Instrument Volume | Φ260×420(H)mm |
Instrument Net Weight | 3kg |
On-Resistance | ≤0.5Ω |
Insulation Resistance | ≥1MΩ |
