Irradiator AIT-T20

Technical Parameters

Responsetime(95%response)

＜20S

Zero-point Offset

The Response to a 5K/h Change in Ambient Temperature

＜2W/m²

Annual Stability Error

≤2%

Nonlinear Error

＜2%

Directional Error

＜30W/m²

Temperature Response Error(-10℃ to+40℃)

＜6%

Tilt Response Error

＜1.5%

Working Temperature

-40℃~+85℃

Internal Resistance

＜50Ω

Measurement Range

0~2000W/m²

Spectral Range(50%transmittance)

280mm~3000mm

Signal Output

RS485

Power Supply（V）

DC12V

Sensitivity Range

≥7μV（W/m²）

Weight(Excluding Signal Cable)

0.8kg

Protection Grade

IP67

Whether the Desiccant Needs to Be Replaced

NO

Calibration Traceability

Traceability WRR

Suggested Calibration Cycle

Once every two years
